This large, robust marking gauge is designed to fit comfortably in your hand for a secure grip. It has a 3''-wide stainless steel referencing face to provide ample contact with workpiece surfaces. The round, beveled A2 steel blade slides on a detented post and reaches up to 6'' for scribing crisp, clean layout lines. Each revolution of the dial moves the cutter 1/16'', and micro-adjustment collars fine-tune the setting down to 1/256''. The replaceable wheel cutter retracts into the marking body when not in use for safety and to preserve its razor-sharp cutting edge.
JessEm Wood Sabre Imperial Marking Gauge Details:
Delivers consistent pressure and control when scribing lines up to 6'' from the gauge body
Round, beveled A2 steel wheel cutter is hardened to 60 RC for durability
Wheel cutter can be retracted inside the reference face when not in use
Large (just under 3'') stainless steel reference face is located 3/4'' below the cutter for smooth sliding and controlled cutting pressure
Spring-loaded ball bearing interfaces with detents spaced 1/2'' apart on guide post, for quick macro-adjustment
Micro-adjuster with laser-engraved markings at 1/2'' intervals and 1/16'' fine adjustment per revolution
Graduated collar allows micro-adjustment down to 1/256''
Crafted from 6061 aluminum and high-quality stainless steel for exceptional durability
